HKS Turbo Timer X (41001-Ak009)

10th generation Turbo Timer evolutionally advanced with the turbo engines. The original turbo timer was developed to prevent turbocharger bearing seizure by after-idling. Simple and Highly Operable Model from 35-year History

Spec:

• Single button control and red LED numerical display simplify operation and improve visibility.
• 5 time ranges selectable between 1, 3, 5, 10, and 30min. Maximum timer duration is 30 minutes.
• Accurate time duration can be selected by manual setting.
• Handbrake detective safety circuit
• High capacity relay
• Timer operation stops under unstable conditions caused by low voltage of a battery, etc.

Simple, and easy to use

■Application：　Turbo vehicles that start the engine using the ignition key.

• Not applicable to a vehicle equipped with the push-button ignition.
• Existing Turbo Timer Harness is compatible.
  ※This product is not compatible some vehicles. Refer to the application list before purchasing this product.

Features

• Simple after-idling function and easy operation
• Optimal touch button size for simple operation
• Wavy panel design around the button for better operability. Capable of operating the button even in the dark.
• Accurate setting is possible even by quick operation.
• One-digit display for easy recognition of the set time
• Time duration changed simply by pushing the button. Intuitive operations is possible.
• One seven-segment LED simply shows the timer setting.
• Selecting “OFF mode” turns off the display and buzzer.

●Extension of Timer Duration

• Maximum timer duration is 30 minutes.
  Not only protecting the turbocharger, but also maintaining the temperature in a vehicle in summer and winter is possible.

• DC12V Negative Ground （Operation Voltage: DC101～16V）
• Large Capacity Relay Equipped
  Ignition: 25A / Accessary: 25A
• Ignition: 25A / Accessary: 25A
• Operating Temperature: -20～60℃（-4 to 140°F）
• Setting Time Range: ：1,　3,　5,　10, and 30 min.
