AP Aluminium Caliper(BCE)LHNx35,6-CP4240
12 products sold in last 4 hours
Selling fast! Over 3 people have in their cart
21 people are viewing this right now
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
Applications:
– GT Cars Front & Rear.
Features:
– Radial Mount, 210mm centres.
– Radical new asymmetric design concept.
– Superior dynamic performance.
– Ducted Air cooling features, significantly reduces caliper temperatures.
– Monobloc Aluminium alloy body.
– CP6077 small bore version.
– Designed to operate on Carbon or Iron Discs.
– Internally ported.
– Titanium pistons.
– Carbon ducts fitted.
– Dry Breaks fitted.
Part Numbers:
– Calipers with Ø27.0, Ø31.8 & Ø38.1mm Bores.
– RH = CP6078-4S7MPD
– LH = CP6078-5S7MPD
– Calipers with Ø26.0, Ø27.0 & Ø31.8mm Bores.
– RH = CP6077-4S7MPD
– LH = CP6077-5S7MPD
 Downloads (click highlighted text opposite) |
CP6077cd CP6078cd |
| Brake Pad Information (To view larger image of pad click on Pad Part No) |
– CP3558D54 Iron Pad Pad Area = 77.4cm³ Pad Depth = 54.0mm Thickness = 25.0mm – CP4240 Carbon pad Pad Area = 78.12cm³ Pad Depth = 54.0mm Thickness = 25.0mm |
| TECHNICAL SPECIFICATIONS | |
| Piston Sizes – mm | – CP6077 = Ø26.0 x 2 / Ø27.0 x 2 / Ø31.8 x 2 – CP6078 = Ø27.0 x 2 / Ø31.8 x 2 / Ø38.1 x 2 |
| Piston area = cm² | 50.1 |
| Disc Diameter – mm | 355.0 |
| Disc Thickness – mm | – Iron = 36.0 – Carbon = 35.0 |
| Weight (no pads) – Kg | 2.25 |
| Hydraulic Threads | M10x1.0 |
| Mounting Type | Radial |
| Mounting Centres – mm | 210.0 |
| Mounting Offset – mm | 42.0 |
| Mounting Hole Ø – mm | 12.15 |
| ‘PL’ Dimension – mm | 63.5 |
| Bleed Screw Tightening Torque | N/A |
| Dry Break Tightening Torque | 13Nm |
| SPARE PARTS | |
| Pistons | – Ø26.0mm = CP6057-104 – Ø27.0mm = CP6055-110 – Ø31.8mm = CP6055-111 – Ø38.1mm = CP6055-112 |
| Seal Repair Kit | – CP6077 = CP4518-BCE – CP6078 = CP4518-CEJ |
| Pad Retainer | N/A |
| Pad Retainer Bolt | N/A |
| Wear Plates | – CP6075-107 x 4 – Ctr Beam = CP6078-104 x 1 |
| Pad Supports | CP6078-105 x 4 |
| Anti-knockback Springs | CP6518-7LBSSL |
| Bleed Screw | N/A |
| Fluid Pipe | N/A |
| Dry Break Fitting (To view more Dry Break information select text above) |
CP6300-21 |
| Carbon Duct Kit | CP6078-107 |
| AVAILABLE OPTIONS | |
| Thermo Sensor | – RH = CP6282-2 – LH = 6282-3 |
| Piston Caps | – Ø26.0mm = CP6292-190 – Ø27.0mm = CP6292-168 – Ø31.8mm = CP6060-128 – Ø38.1mm = CP5842-118 |
?
