AP Racing Acal(H)Rhnx09 7-Cp2399
13 products sold in last 7 hours
Selling fast! Over 16 people have in their cart
29 people are viewing this right now
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
Applications:
– Lightweight formula cars front.
– Rally / circuit rear.
Features:
– Radial mount, 95mm x 30.5mm centres.
– Aluminium alloy body.
– Suits Ø267mm x 9.7mm solid disc.
– versions are available for for up to Ø300mm disc.
– Aluminium Pistons.
– quick release ‘R’ Clip pad retainer
Part Numbers:
– Ø44.5mm Bore – CP3677-4E0.
– Ø41.3mm Bore – CP3676-4E0.
– Ø36.0mm Bore – CP4586-4E0.
– Ø31.8mm Bore – CP4596-4E0.
 Downloads(click highlighted text opposite) |
CP3676cd CP4586cd |
| Brake Pad Information (To view larger image of pad click on Pad Part No) |
CP2399D43 . Pad Area = 27.4cm³. Pad Depth – 42.9mm Thickness = 14.4mm |
| TECHNICAL SPECIFICATIONS | |
| Piston Sizes – mm | – CP3676 = Ø41.3 – CP3677 = Ø44.5 – CP4586 = Ø36.0 – CP4596 = Ø31.8 |
| Disc Diameter – mm | Ø267.0 |
| Disc Thickness – mm | 9.7 |
| Weight (no pads) – kg | 1.1 |
| Hydraulic Threads | 3/8″x24UNF |
| Mounting Type | Radial |
| Mounting Centres – mm | 95.0 |
| Mounting Offset – mm | 30.5 |
| Mounting Hole Ø – mm | 10.1 |
| ‘PL’ Dimension – mm | 47.33 |
| Bleed Screw Tightening Torque | 17Nm |
| SPARE PARTS | |
| Pistons | – CP3676 = CP2576-105 – CP3677 = CP2577-102 – CP4586 = CP3177-102 – CP4596 = CP3178-102 |
| Seal Repair Kit | – CP3676 = CP4518-K – CP3677 = CP4518-L – CP4586 = CP4518-H – CP4596 = CP4518-E |
| Pad Retainer | CP2213-17 |
| Bleed Screw | CP3720-182 |
| Fluid Pipe | N/A |
?
